Cudy AP3600 Indoor BE3600 Wi-Fi 7 Access Point

Description

Key Features & Specifications of Cudy AP3600 Indoor BE3600 Wi-Fi 7 Access Point

Key Features:

1. Broadcom 2GHz Quad-Core CPU
2. 4-Stream Dual-Band Wi-Fi 7
3. 2882 Mbps + 688 Mbps Wi-Fi
4. 1× 2.5GbE PoE In, 1× GbE PoE Out
5. 802.3at, Passive PoE, DC
6. Watchdog, Schedule Reboot
7. Multi-AP Management
8. Captive Portal, Multi-SSID
9. 200 Connected Devices
10. Covers 120m² (1300 ft²)

Specifications:

1. Version: AP3600 1.0
2. CPU: 2GHz Quad-Core, ARM Cortex-A7
3. Flash/ROM Storage: 128 MB (1 Gbit) NAND
4. DDR/RAM: 512 MB (4 Gbit) DDR3L
5. 5 GHz Wi-Fi Speed: 2882 Mbps
6. 2.4 GHz Wi-Fi Speed: 688 Mbps
7. 5 GHz Wi-Fi Streams: 2 Spatial Streams
8. 2.4 GHz Wi-Fi Streams: 2 Spatial Streams
9. Wi-Fi Antennas: 4× Internal
10. Beamforming: Yes
11. FEM or PA/LNA: 5GHz: 2× Internal | 2.4GHz: 2× Internal
12. Range Performance: Max 220m (722 ft)
13. 2.5G RJ45 Port: 1
14. Gigabit RJ45 Port: 1
15. Ethernet Notes: Accepts PoE powering
16. LED: System
17. Physical Buttons: Reset Button
18. Power Interfaces: DC Jack | PoE via Ethernet Port
19. Power Methods: DC | Passive PoE | 802.3at/af PoE
20. Power Input: DC: 12V=1A | Passive PoE: 48-57V= | PoE: 802.3at/af
21. Output: 24V=Passive PoE
22. Adapter Input: 100-240V, 50/60Hz
23. Output: 48V= Passive PoE
24. Max Power Consumption: 10W
25. Advanced Hardware Watchdog: Yes
26. EMC: ESD: Contact: 4kV; Air: 8kV
27. Operating Temperature: 0 to 40℃
28. Storage Temperature: -40 to 70℃
29. Humidity: 10% to 90% non-condensing
30. Storage Humidity: 5% to 95% non-condensing
31. Installation: Wall-mount | Ceiling-mount
32. Wi-Fi Standards: Wi-Fi 7
33. Max Wi-Fi Modulation: 4K-QAM
34. Wi-Fi Efficiency: MLO | MRU | Puncturing | OFDMA | MU-MIMO | BSS Color
35. Wi-Fi Efficiency Note: MU-MIMO on 5GHz
36. Max Capacity: 512
37. Recommended Client Upper Limit: 200
38. Max Wi-Fi Channel Width: 160 MHz
39. Wi-Fi Security: WPA/WPA2/WPA3
40. Multi-SSID (Max): 8 SSIDs (Up to 4 SSIDs on each band), VLAN Support
41. WPS: Yes
42. Operation Modes: Wi-Fi Router | Access Point
43. Mesh: Cudy Mesh
44. Mesh Backhaul: Wireless Backhaul | Wired Backhaul
45. Multi-Band Backhaul: Yes
46. WAN Mode: DHCP | Static IP | PPPOE | PPTP | L2TP
47. IP Versions: IPv4/IPv6
48. LED Control: Yes
49. Reliability: Timed Reboot | Backup & Restore
50. Charts: Mesh Topology | Internet Speed | Wi-Fi Speed
51. Certifications: FCC, CE
