ASUS RT-AX52 AX1800 Dual Band WiFi 6 Extendable Router

Description

ASUS RT-AX52 AX1800 Dual Band WiFi 6 Extendable Router

Specifications:

General Information:

1. Antenna: External antenna x 4
2. Processor: 1.3GHz dual-core processor
3. Memory: 128 MB Flash | 256 MB RAM
4. Boosts speed: OFDMA (Orthogonal Frequency Division Multiple Access) | Beamforming: standard-based and universal | 1024-QAM high data rate | 20/40/80 MHz bandwidth
5. Operating Frequency: 2.4GHz / 5GHz
6. Ports: RJ45 for Gigabits BaseT for WAN x 1 | RJ45 for Gigabits BaseT for LAN x 3
7. Button: WPS Button, Reset Button, Power Switch
8. LED Indicator: Power x 1 | WAN x 1 | LAN x 3 | 2.4G x 1 | 5G x 1 | WPS x 1
9. Power Supply: AC Input: 110V~240V(50~60Hz) | DC Output: 12 V with max. 1 A current
10. AiMesh: Primary AiMesh Router | AiMesh Node
11. Wireless: UTF-8 SSID | WiFi MAC Address Filter | Wireless Scheduler | Airtime Fairness | RADIUS Client | Universal Beamforming | Explicit Beamforming

Network Standard:

1. IEEE 802.11a
2. IEEE 802.11b
3. IEEE 802.11g
4. WiFi 4 (802.11n)
5. WiFi 5 (802.11ac)
6. WiFi 6 (802.11ax)
7. IPv4
8. IPv6

Data Rate:

1. 11a: up to 54 Mbps
2. 11b: up to 11 Mbps
3. 11g: up to 54 Mbps
4. WiFi 4 (802.11n): up to 300 Mbps
5. WiFi 5 (802.11ac): up to 867 Mbps
6. WiFi 6 (802.11ax) (2.4GHz): up to 574 Mbps
7. WiFi 6 (802.11ax) (5GHz): up to 1201 Mbps

Traffic Control:

1. Bandwidth Limiter: Traditional QoS
2. Traffic Monitor: Real-time Traffic Monitor | Wired Traffic Monitor | Wireless Traffic Monitor

WAN:

1. PPPoE | PPTP | L2TP | Automatic IP | Static IP
2. Dual WAN

Port triggering

1. DMZ
2. DDNS

LAN:

1. DHCP Server
2. IGMP Snooping
3. IPTV
4. Manually Assign IP Address
5. Wake on LAN (WOL)

VPN:

1. Instant Guard
2. VPN Client L2TP
3. VPN Client Open VPN
4. VPN Client PPTP
5. VPN Server IPSec
6. VPN Server Open VPN
7. VPN Server PPTP

Administration:

1. Configuration Backup and Restore
2. Diagnosis tools
3. Feedback System
4. System Log
